Claw Type Grinder – 3-33t/h Fine Grinding Solution for Grains, Bran & Starch

Contact
The SYFC66 Series Claw Type Grinder is a high-efficiency fine pulverizing equipment designed for the feed industry, flour processing, food manufacturing, chemical industry, and Chinese herbal medicine processing. With a power range of 55–315 kW and a capacity of 3–33 tons per hour, this grinder delivers exceptional fine grinding performance with particle fineness reaching 40–120 mesh or higher.

 Claw Type Grinder – 3-33t/h Fine Grinding Solution for Grains, Bran & Starch

Working Principle

This grinder features a specially designed disk equipped with multiple teeth and claws. The impact poles drive the rotor disk and hammers at high speed, creating a powerful grinding action through:

  • Impact – High-speed collision breaks down material particles

  • Cutting – Sharp edges shear fibrous materials

  • Rubbing – Friction between particles and grinding elements refines size

  • Tearing – Mechanical force separates tough structures

  • Pressing – Compression further reduces particle dimensions

This multi-action grinding mechanism ensures thorough size reduction even for materials that are typically challenging for standard grinding equipment.

Core Product Features

1. Versatile Application Across Multiple Industries
The SYFC66 Series is suitable for a wide range of industries: feed processing, flour milling, food production, chemical manufacturing, and Chinese herbal medicine processing. It efficiently handles grains, wheat, beans, grain husks, bran, starch, and other hard-to-crush materials.

2. Ultra-Fine Grinding Capability
Achieves crushing fineness of 40–120 mesh or higher, meeting demanding particle size requirements for fine powder production across various industries.

3. High-Efficiency Multi-Action Grinding
The claw-type design combines impact, cutting, rubbing, tearing, and pressing actions in a single machine, delivering superior grinding efficiency compared to conventional hammer mills.

4. Durable & Reliable Construction
Built with high-quality materials and precision engineering, the SYFC66 Series ensures long service life and stable performance even under continuous heavy-load operation.

5. Stable Operation & Low Maintenance
The compact structural design minimizes vibration and noise, while the optimized layout simplifies routine maintenance and cleaning procedures.

Technical Specifications

Model Rotor Diameter (mm) Dynamic Hammer (pcs) Impact Column (pcs) Fixed Grinding Teeth (pcs) Power (kW) Capacity (t/h) Overall Size (mm)
SYFC66×60 660 24 42 167 55 3–8 2175×1340×1455
SYFC66×60 660 24 42 167 75 4–9 2175×1340×1455
SYFC66×80 660 32 56 206 90 5–10 2620×1340×1455
SYFC66×80 660 32 56 206 110 6–11 2620×1340×1455
SYFC66×100 660 40 70 270 132 7–13 3020×1340×1455
SYFC66×100 660 40 70 270 160 8–15 3020×1340×1455
SYFC66×125 660 48 84 334 180 9–17 3530×1340×1455
SYFC66×125 660 48 84 334 220 11–22 3530×1340×1455
SYFC66×160 660 64 122 454 285 15–27 4330×1340×1455
SYFC66×160 660 64 122 454 315 19–33 4330×1340×1455

Applications

Industry Applications
Feed Industry Grain grinding, poultry & livestock feed production
Flour Industry Wheat milling, fine flour processing
Food Industry Bean grinding, starch processing, food ingredient preparation
Chemical Industry Fine powder production for chemical raw materials
Chinese Herbal Medicine Pulverizing medicinal herbs and plant materials
Hard-to-Crush Materials Bran, husks, fibrous grains, and other challenging substances

Comparison: Claw Type Grinder vs. Hammer Mill

Feature SYFC66 Claw Type Grinder Standard Hammer Mill
Grinding mechanism Impact + cutting + rubbing + tearing + pressing Primarily impact
Fineness range 40–120 mesh or higher Typically coarser
Hard-to-crush materials Excellent performance Limited effectiveness
Energy efficiency High for fine grinding Lower for fine applications
Applications Feed, flour, food, chemical, herbal Primarily feed and grain

Why Choose SYFC66 Claw Type Grinder?

Advantage Benefit
Multi-action grinding Superior fine grinding performance
40–120 mesh fineness Meets diverse powder specification requirements
Wide industry application Single machine serves multiple production needs
Hard-to-crush capability Processes materials that clog standard grinders
Multiple model options 3–33 t/h capacity for various production scales
Stable operation Low vibration, reliable continuous production
